Supported capture formats for Matrox A/V Tools
Supported capture formats for Matrox A/V
Tools
The following table lists the supported capture formats on Matrox MXO2
products, based on your editing video format and selected input source in Matrox
A/V Tools.
Matrox MXO2 input
Editing video format
(capture format)
1
HDMI SDI
2
Component S-Video Composite
NTSC NTSC
3
, 720p @ 59.94 fps, or 1080i/p
4
/PsF @ 29.97 fps NTSC NTSC
PAL PAL
5
, 720p @ 50 fps, or 1080i/p
4
/PsF @ 25 fps PAL PAL
486p @ 23.98 fps 1080p @ 23.98 fps 1080p
4
/PsF @23.98 fps — —
486p @ 29.97 fps — — — — —
576p @ 25 fps — — — — —
720p @ 23.98 fps — — — — —
720p @ 25 fps — — — — —
720p @ 29.97 fps — — — — —
720p @ 50 fps PAL
5
, 720p @ 50 fps, or 1080i/p
4
/PsF @ 25 fps PAL PAL
720p @ 59.94 fps NTSC
3
, 720p @ 59.94 fps, or 1080i/p
4
/PsF @ 29.97 fps NTSC NTSC
1440×1080i @ 25 fps —
——
——
1440×1080i @ 29.97 fps —
——
——
1440×1080p @ 23.98 fps — — — — —
1440×1080p @ 25 fps — — — — —
1440×1080p @ 29.97 fps — — — — —
1080i @ 25 fps PAL
5
, 720p @ 50 fps, or 1080i @ 25 fps PAL PAL
1080i @ 29.97 fps NTSC
3
, 720p @ 59.94 fps, or 1080i @ 29.97 fps NTSC NTSC
1080p @ 23.98 fps 1080p @ 23.98 fps 1080p
4
/PsF @ 23.98 fps — —
1080p @ 24 fps 1080p @ 24 fps 1080p/PsF @ 24 fps — — —
1080p @ 25 fps PAL
5
, 720p @ 50 fps, or 1080p
4
/PsF @ 25 fps PAL PAL
1080p @ 29.97 fps NTSC
3
, 720p @ 59.94 fps, or 1080p
4
/PsF @ 29.97 fps NTSC NTSC
1080p @ 30 fps 1080p @ 30 fps — — —
1
Video is always captured to the editing video format.
2
SDI is not supported on Matrox MXO2 Mini.
3
NTSC is not supported on the HDMI input.
4
1080p is not supported on the component input.
5
PAL is not supported on the HDMI input.
