Operating Instructions – Labmaster
©
130 and MB20G Systems
Instruction Manual
Chapter 5: System Screens
© MBraun, Inc. Edition 1/2007 Page 5-6
Functions Screen 2
Accessed via Functions Screen 1 by
touching the Next button.
Antechamber 2 buttons are permanently
grayed out when only one large
antechamber is present on the system.
Button
Description
Used to start an automatic antechamber cycle for
the large antechamber.
Used to evacuate the large antechamber in
manual mode.
Used to refill the large antechamber in manual
mode.
Used to activate the vacuum pump for the
antechamber. (This is activated automatically
when the antechamber is operated using the
purifier vacuum pump.)
