Operating Instructions – Labmaster
©
130 and MB20G Systems
Instruction Manual
Chapter 8: Commissioning the System
© MBraun, Inc. Edition 1/2007 Page 8-4
8.4 Purging the System
Systems equipped with freezers or other components that may be
protected by covers must be open during the purging process.
If the system has been in use prior to purging, ensure that the
freezer(s) is deactivated and is at room temperature before
beginning the process.
The instructions below include information regarding glovebox systems equipped with
analyzers. The analyzers, which are used to monitor the oxygen and moisture levels inside the
glovebox, can be used to determine when the glovebox atmosphere reaches the desired purity
level.
Glovebox systems which are not equipped with analyzers require the gas consumption to be
monitored to determine when the glovebox atmosphere reaches the desired purity level. Refer
to the Gas Consumption chart in Chapter 3 for more information.
Box Purge Volume Table
Box Length 1250 Box Length 1500 Box Length 1800
Box Depth 780
13,000 liters 14,000 liters 18,000 liters
Box Depth 1000
14,000 liters 18,000 liters 22,000 liters
Box Depth 1200
18,000 liters 22,000 liters 26,000 liters
Adjusting the Parameters
Adjusting the parameters is only necessary when using the
Reverse or Manual purge methods.
Touch the Box Pressure/Analyzer display box on
the start screen.
