77
© 2013 McNeilus Truck and Manufacturing, Inc.
Contender Front Loader
Operation
2. Turn the air pressure control valve to the PRESSURIZE
position (Figure 37, Item 1). The water tank will be
pressurized from the chassis air system.
3. The air gauge (Figure 37, Item 2) will read the pressure in
the water tank. The pressure must not exceed 55 psi.
PRESSUR
IZE
EXHAUST
PR
ES
SURE
W
AT
ER
SYSTEM
OFF
WAR
N
I
N
ADV ERTENCIA
2
0
0
4
0
6
0
80
100
!
!
G
2
1
Figure 37
4. Connect a hose to the tting (Figure 38, Item 1).
WARNING
Do not drink the water.
Serious internal injury may result.
5. Open the valve (Figure 38, Item 2).
2
1
Figure 38
