TA80V User Manual
Touch the Pressure
Sensor Zero calibration " .
Note the prompt
information, disconnect all
air sources, and empty the
gas in the machine
through the flow
meter,and put the animal
breathing circuit with the
air.
Step 4
Touch the Start and a
progress bar displays the
calibration.
Step 5
After the calibration
finished, info indicating
whether the verification is
successful or not will be
displayed; touch the
button to return to
complete the pressure
zero calibration.
7.3.2. Pressure Sensor Calibration
During use or testing, if it is found that the measured PEEP is still too different from the set PEEP
value (2cmH2O) after stabilization, please perform PEEP calibration. During calibration, you need to
turn on the compensation flow to 3L/min, and ensure that the bellows is intact and has no air leakage.
Then block the animal interface on the animal tee to make the bellows bag reach the top, and then
perform the following process.
Step 1
