TA80V User Manual
2.4.6. Screen Display
Ventilation parameter monitoring, settings and information prompts of the entire ventilator are
displayed on the entire HD touch screen.
2.4.6.1. Standby Interface
Figure 2-7 shows the standby interface. In the menu area on the right side of the screen, the lower
side is the parameter area, the upper part is the alarm information prompt, power information prompt
and ventilation mode display, and the standby time is displayed in the middle. When a menu pops up,
the middle area will be covered.
Figure 2-7 Standby screen
2.4.6.2. Work Interface
Touch the in the standby interface to enter the work interface, as shown in Figure 2-8. Touch the in the
working interface to return to the standby interface. In the standby interface, the ventilator is in standby mode and
cannot work.
Figure 2-8. The working interface
