TA80V User Manual
74
9.8.3. Ventilation Mode Setting
The system has the following ventilation modes: the parameters that can be set in each ventilation
mode are also different. See table below.
Ventilation mode
Parameters Setting
VCV
Weight、TV、Freq、I：E、F_Trig、PEEP
PCV
Weight、PInsp、Freq、I：E、F_Trig、PEEP
SPONT
Weight、TV、Freq、I：E、F_Trig、
MANUAL
Weight、TV、Freq、I：E、F_Trig、PEEP
DEMO
Weight、TV、Freq、I：E、F_Trig、PEEP
9.8.4. The Ventilation Parameter Setting
Ventilation parameters
Setting range
Resolution
Weight
2-100kg
0.1kg
Tidal volume TV
50 ~ 1500mL
1mL
Breathing rate Freq
1 ~ 150bpm
1 bpm
Inspiratory to expiratory
I:E
9.9：1 ~ 1：9.9
0.1
Air-holding time Hold
0 ~ 50%
1%
Flow rate trigger
sensitivity F _ Trig
0.5 ~ 20L/min ，OFF
0.5L/min
Pressure-triggered
sensitivity P _ Trig
-1 ~ -20 cmH 2O，OFF
1 cmH 2O
Ppressure PEEP
3~ 20 cmH 2O，OFF
1 cmH 2O
Inspiratory pressure
PInsp
2~ 60 cmH 2O
1 cmH 2O
9.8.5. Gas Mechanics
Gas source:
Anesthesia system
Gas components:
O
2
or Air
Rated gas supply
pressure:
300kPa
Pressure range at
inlet:
280 ~ 600kPa
Flow valve range:
3 ~ 100L/min
output:
Pressure range: 0 ~ 6kPa; flow rate range: 3 ~ 100L / min
