TA80V User Manual
7.5. Replacement of Fuse
Warning Before replacing the fuse, the AC power must be disconnected. Otherwise, it will
cause injury to personnel and even death.
Warning The fuse of the same model and size must be replaced when replacing the fuse, t
Otherwise, the equipment will be damaged.
Warning The fuse is a vulnerable part, which shall be replaced with appropriate force and
speed.
1. Fuses located behind the ventilator (see Figure 5-1) with replacement steps as follows:
1) Insert the screwdriver into the groove at the end of the fuse box
2) Turn counterclockwise for 3-5 turns and then gently pull out the
fuse holder
3) Remove the fuse
4) Install a new fuse
5) Gently push the fuse holder into its original position
6) Then use a screwdriver to turn it clockwise 3-5 times to fix it
Figure 5-1 Back of Ventilator
Attention
When turning with a screwdriver, do not use excessive force or force, otherwise the
fuse box may be damaged.
