Meditech TA80V - Technical Specification for the Respiratory System

TA80V User Manual
71
9.7. Technical Specification for the Respiratory System
Fresh gas
compensation
Flow compensation range: 0 ~ 10L / min
gas:O
2
, AIR, air, and anesthetic
Absorbent:
1500ml absorption tank (single)
linkage:
Common gas outlet: Type ISO5356 type connector (standard 22mm outer
diameter or 15mm inner diameter, tapered friction connector).
Respiratory
system leak:
These values guarantee continuous pressure, higher than the expected
pressure during mechanical ventilation.
At the pressure of 3 kPa (0.4 psi), the leakage flow rate is 150ml / min.
Respiratory
resistance
At a flow rate of 60 l / min, expiratory resistance is 0.6 kPa; inspiratory
resistance is 0.6 kPa.
At a flow rate of 30 l / minute, expiratory resistance: 2.2 kPa; inspiratory
resistance: 2.2 kPa.
To ensure compliance with the standards, the animal patient circuit with small
flow resistance should be selected.
APL valve
resistance
At the flow rate of 3 liters / minute, the flow resistance is: 0.05 ~ 3 kPa;
At a flow rate of 30 l / min, the flow resistance is: 0.1 ~ 0.5 kPa.
Connector leak
(APL valve completely closed) leak flow of 50 ml/min.
One-way valve
resistance
Dry state: 0.15 kPa
Pressure generated from the wet check valve: <0.14 kPa
Pressure for opening the wet check valve: <0.1 kPa
Absorption circuit
compliance
<50ml/kpa
