Operator's Manual English 41
Table 6. Operational Defaults (continued)
Item Available settings Default
Date format DD MM YYYY, YYYY MM DD, MM
DD YYY
MM DD YYYY
This setting may be changed by an authorized techni‐
cian.
Language Danish, Dutch, English, French,
German, Greek, Hungarian, Italian,
Norwegian, Polish, Portuguese,
Romanian, Russian, Slovak, Span‐
ish, Swedish
English
This setting may be changed by an authorized techni‐
cian.
Trend line averaging ON, OFF OFF
See Turning Trend Line Averaging On/Off, page 57
Trend axis view TWO AXIS VIEW, ONE AXIS VIEW ONE AXIS VIEW
See Changing the Trend View - Two Graphs or One
Graph, page 56
Trend time scale (x-axis) 1, 2, 4, 8, 12, 24 hours 1 hour
See Zooming the Trend View, page 58
Sensor placement
sequence
4, 3, or 2 sensors 4 sensors
See Changing the Sensor Placement Sequence,
page 46
AUC threshold type FIXED, % BELOW BASELINE FIXED
See Changing the AUC Threshold, page 71
AUC threshold FIXED: 30 - 60
% BELOW BASELINE: 0 - 30%
FIXED: 50
% BELOW BASELINE: 25%
See Changing the AUC Threshold, page 71
Serial port OFF, PC LINK 1, PC LINK 2, CLINI‐
CAL TEST SETUP, VUE LINK
OFF
This setting may be changed by an authorized techni‐
cian.
4.5. Menu Structure
Table 7. Menu Structure
MENU ALARM LIMITS UPPER LIMITS
LOWER LIMITS
SETTINGS GENERAL SCREEN BRIGHTNESS
SENSOR PLACEMENT SEQUENCE
ALARMS ALARM VOLUME
TRENDS TREND LINE AVERAGING
TWO AXIS VIEW/ONE AXIS VIEW
EVENTS
CASE HISTORIES
a
SET BASELINES
b
AREA UNDER CURVE
2
RESET AUC
THRESHOLD
a
Available only when no sensors are connected to the monitoring system.
b
Available only when monitoring has begun.
