Medtronic INVOS - Table 15. Case Data Downloads (PC LINK 1 and PC LINK 2) - Data Fields

5
Operator's Manual English 85
Table 15. Case Data Downloads (PC LINK 1 and PC LINK 2) - Data Fields
Field Included in PC
LINK 1 format
Included in PC
LINK 2 format
Description
Version ✓ <major>.<minor>.<patch>.<build>/[event list version]/ [output for‐
mat version]
Example: 1.2.34.56/1/1
(For Medtronic use only)
Date ✓ ✓ Date of the reading
Format: MM/DD/YY
Time ✓ ✓ Time of the reading
Format: HH:MM:SS (24-hour format)
Ch label ✓ Range: A to Z, S1 to S4
0 = Channel not active
rSO
2
✓ ✓ Current rSO
2
reading for channel. (Integer)
Range: 15 to 95
0 = Channel not active
Event ✓ ✓ An event that was marked between the last transmission and this
transmission. (Integer)
Range: 0 to 160, 252 to 254
See Event Codes for Data Downloads, page 85 for descriptions.
0 = No event
Status ✓ ✓ Current active status. (Integer)
Range: 0 to 21
See Status Codes for Data Downloads, page 88 for descriptions.
0 = No status
Baseline ✓ Current baseline value. (Integer)
Range: 15 to 95
AUC ✓ Area Under the Curve. (Integer)
Range: 0 to 9999
UAL ✓ Upper Alarm Limit. (Integer)
Range: 20 to 95
LAL ✓ Lower Alarm Limit. (Integer)
Range: 15 to 90
A ✓ ✓ Zero, to maintain backwards compatibility.
Format: 0.0000
B ✓ ✓ Zero, to maintain backwards compatibility.
Format: 0.0000
C ✓ Zero, to maintain backwards compatibility.
Format: 0
Rsvd
(Reserved)
✓ ✓ Zero, to maintain backwards compatibility.
Format: 0
Channel n sen‐
sor ID
✓ ✓ String (14 characters) - if a sensor is connected.
0 = No sensor connected
5.6.3. Event Codes for Data Downloads
The following event codes apply to case histories downloaded from the monitoring system
via USB and case data transmitted via the monitoring system’s serial port.
