80 Operator's Manual English
parameter system operator should not rely on the multi-parameter system for generating
alarms.
The following instructions explain how to transmit real-time data to a Philips IVOI module
for display on a Philips multi-parameter system. The data transmitted includes rSO
2
values,
alarms, and status messages.
Hardware requirements for communicating with a Philips VueLink™* module or Philips
IntelliBridge™* EC10 module are described in Table 13.
Table 13. Hardware Requirements for Philips VueLink™* and IntelliBridge™* Communication
System Hardware requirements
Philips VueLink™* System •
Philips VOI B module (Philips VueLink™* P/N M1032A #A05)
•
Philips VOI/RS-232 Interface Cable (Philips VueLink™* P/N M1032 #K6B)
•
VueLink™* adapter cable, DB25F to DB9F (Medtronic P/N VLI)
Philips IntelliBridge™* System •
Philips IntelliBridge™* module (EC10)
•
Philips Ethernet Cable
•
Philips IntelliBridge™* EC5 Open Interface RS232 Cable
To set up communication with a Philips VueLink™* module:
1. Slide the Philips VOI B module into any of the open slots in the multi-parameter
system, making sure it locks into place.
2. Connect the VOI/RS-232 Interface Cable to the VOI B module.
3. Connect the VOI/RS-232 Interface Cable via the VueLink™* adapter cable to the
serial port on the monitoring system docking station (Figure 67, page 79).
4. Tighten all screw locks at each connector junction.
5. Ensure that the Philips monitor and VOI B module are properly configured per
Philips instructions.
6. Power on the monitoring system and set the serial port protocol to VUE LINK, as
described in the monitoring system's service manual. After the monitoring system
restarts, it begins communicating with the Philips monitor.
7. Begin a case as described in Set Up for Patient Monitoring, page 42.
To set up communication with a Philips IntelliBridge™* module:
1. Insert the Philips IntelliBridge™* EC10 module into any of the open slots in the
multi-parameter system, making sure it locks into place.
2. Connect the Ethernet cable to the IntelliBridge™* EC10 module.
3. Connect the other end of Ethernet cable to the IntelliBridge™* EC5 ID module.
4. Using the IntelliBridge™* EC5 Open Interface RS232 cable, connect the
IntelliBridge™* EC5 ID module to the serial port on the monitoring system docking
station (Figure 67, page 79).
5. Tighten all screw locks at each connector junction.
6. Ensure that the Philips monitor and IntelliBridge™* module are properly configured
per Philips instructions.
