5.6.1.2. Data Format - Case History Downloads
Downloaded case history data is stored in ASCII format as a single line as shown below.
Each field is separated by two space characters. Data is transmitted on a per channel basis
(Channel 1 through Channel 4). See Table 14, page 83 for field descriptions.
Column: A B C D E F G
Description: Version Date Time Ch 1 rSO
2
Event Status Rsvd
Column (continued): H I J K
Description (continued): Ch 2 rSO
2
Event Status Rsvd
Column (continued): L M N O
Description (continued): Ch 3 rSO
2
Event Status Rsvd
Column (continued): P Q R S
Description (continued): Ch 4 rSO
2
Event Status Rsvd
Column (continued): Terminating character
Description (continued): 0x0A
Table 14. Case History Downloads - Data Fields
Field Description
Version
<major>.<minor>.<patch>.<build>/[event list version]/[output format version]
Example: 1.2.34.56/1/1
(For Medtronic use only)
Date Date of the reading
Format: MM/DD/YY
Time Time of the reading
Format: HH:MM:SS (24-hour format)
Ch
n
rSO
2
rSO
2
reading for channel
n
. (Integer)
Range: 15 to 95
0 = Channel not active
Event Current event. (Integer)
Range: 0 to 160, 252 to 254
See Event Codes for Data Downloads, page 85 for descriptions.
0 = No event
Status Current status. (Integer)
Range: 0 to 19
See Status Codes for Data Downloads, page 88 for descriptions.
0 = No status
Note: Status 21 is not stored in the export file.
Rsvd
(Reserved)
Zero, to maintain backwards compatibility.
Format: 0
5.6.2. Case Data Downloaded via Serial Port
During a case, data is transmitted in ASCII text-based streams in either of two user
selectable formats: PC LINK 1 and PC LINK 2.
