72 Operator's Manual English
Note: Be aware that changes to the AUC threshold are retained across power cycles, so the
current setting may reflect a previous case. Check the setting to make sure that it is
appropriate for your patient.
To change the AUC threshold:
1. After monitoring begins, press MENU.
2. Press AREA UNDER CURVE.
3. At the AUC SUMMARY screen, the type of threshold currently in use is indicated
(see Figure 63, page 71):
•
FIXED, or
•
% BELOW BASELINE
Press to toggle between the two choices.
4. Adjust the value for the threshold by pressing the arrow buttons. The ranges are:
•
FIXED: 30 - 60
•
% BELOW BASELINE: 0% - 30%
5. Press CLOSE.
4.13.3. Resetting AUC Collection
You can reset AUC data collection to zero at any point while monitoring. AUC data
collection restarts at the time of reset.
To reset AUC Collection:
1. After monitoring begins, press MENU.
2. Press AREA UNDER CURVE.
3. At the AUC SUMMARY screen, press RESET AUC (see Figure 63, page 71).
4. Press CLOSE.
4.14. Finish Monitoring
To finish monitoring a patient:
1. Power off the monitoring system by pressing the power button on top of the
monitor for approximately 3 seconds.
2. Disconnect the RSCs from the sensors, and unclip the RSC strain-relief clips, if used.
You can leave the RSCs connected to the preamplifier(s).
3. Carefully remove the sensors from the patient. Dispose of the sensors according to
institution procedures for single-use devices.
