Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
4-19
Alarm monitoring
MPC4 / IOC4T CARD PAIR
In order to use the Adaptive Monitoring function, it must first be activated using the VM600
MPSx software (using the Adaptive Monitoring property sheet of the relevant Processed
Output tab for the appropriate Processing Channel node).
Figure 4-8: Illustration of adaptive monitoring technique
Vibration level
Speed
s1 s2 s3 s4 s5 s6
1.3
1.2
1.0
0.8
0.5
0.3
0.2
