Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
13 - 13
Configuring RS-485 terminations for RS, A and B serial communications
CONFIGURATION OF CPUM / IOCN CARDS
NOTE: In Figure 13-12:
• _x refers to _A or _B. For example, J28_x refers to J28_A used to help configure
group ‘A’ communications and refers to J28_B used to help configure group ‘B’
communications.
• J31_x to J38_x are used to configure/select RS-485 terminations for group ‘A’ or
group ‘B’ as, required.
13.4.3 RS-485 terminations for A and B serial communications – AIM104-COM4
or equivalent
For the AIM104-COM4 or equivalent serial communications module, jumpers on the serial
communications module are used to configure RS-485 terminations.
Each RS-485 differential pair can be terminated in one of six different ways, as shown in
Figure 13-11.
For half-duplex RS-485 (2-wire), only jumpers LK15 and LK16 need to be configured. These
groups should be configured identically.
For full-duplex RS-485 (4-wire), jumper groups LK13 and LK15, and LK14 and LK16 must be
configured identically.
Further details on the RS-485 terminations can be found in Figure 13-11 and Table 13-3.
Table 13-3: RS-485 terminations for A and B serial communications –
AIM104-COM4 or equivalent
Type of
RS-485
Serial
communications
(connector)
Jumper location Jumpers
Half-duplex
(2-wire)
A
Optional serial
communications module
(AIM104-COM4 or
equivalent)
LK15
Half-duplex
(2-wire)
B
Optional serial
communications module
(AIM104-COM4 or
equivalent)
LK16
Full-duplex
(4-wire)
A
Optional serial
communications module
(AIM104-COM4 or
equivalent)
LK13 and LK15
Full-duplex
(4-wire)
B
Optional serial
communications module
(AIM104-COM4 or
equivalent)
LK14 and LK16
