Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
8-3
Attribution of slots in the rack
INSTALLATION
8.2 Attribution of slots in the rack
Table 8-1 shows the installation restrictions that apply to the VM600 system rack (ABE04x).
Table 8-1: Attribution of slots in a VM600 system rack (ABE04x)
Rack
(VME)
slot no.
Card/system component
accepted in front card cage
Card/system component
accepted in rear card cage
00
Reserved for CPUM
Reserved for IOCN
01 RLC16 or IRC4
02 Reserved for VME 32 card RLC16 or IRC4
03 to 14
MPC4, AMC8, CMC16, XMC16,
XMV16 or XMVS16
Associated IOC4T, IOC8T, IOC16T or
XIO16T. Or RLC16 or IRC4.
15
Reserved for RPS6U
(Power supply 2, PS2)
(Width of RPS6U = 3 slots)
RLC16 or IRC4
16 RLC16
17 RLC16
18
Reserved for RPS6U
(Power supply 1, PS1)
(Width of RPS6U = 3 slots)
RLC16
19 Reserved for rear panel associated with
the rack power supply (one or two
RPS6Us)
20
Notes
An MPC4 card must have an IOC4T card installed directly behind it in the rack.
An AMC8 card must have an IOC8T card installed directly behind it in the rack.
A CMC16 card must have an IOC16T card installed directly behind it in the rack.
An XMC16, XMV16 or XMVS16 card must have an XIO16T card installed directly behind it in the rack.
In a VM600 system rack (ABE04x), one or two RPS6U rack power supplies can be installed. the rack can have
two RPS6U rack power supplies installed for different reasons: in order to support rack power supply redundancy
(2.10.5 Racks with two RPS6U rack power supplies in order to support rack power supply redundancy) or in
order to supply power to the cards (2.10.6 Racks with two RPS6U rack power supplies in order to supply power
to the cards).
