HARDWARE MANUAL Document reference MAMPS-HW/E
VM600 machinery protection system (MPS) Edition 18 - March 2022
8-4
Attribution of slots in the rack
INSTALLATION
Table 8-2 shows the installation restrictions that apply to the VM600 slimline rack (ABE056).
Table 8-2: Attribution of slots in a VM600 slimline rack (ABE056)
Rack
slot no.
Card/system component
accepted in front card cage
Card/system component
accepted in rear card cage
03
(default)
MPC4, AMC8, XMC16, XMV16 or
XMVS16
Associated IOC4T, IOC8T or XIO16T
01 None RLC16
Notes
As per the ABE04x rack (above), a signal processing card (such as a MPC4) must have an input/output card
(such as a IOC4T) installed directly behind it in the rack.
A VM600 slimline rack (ABE056) has one rack slot / position in the front and two rack slots / positions in the
rear. In the Rack slot no. column, the factory assigned default values are shown. However, different rack slot
numbers can be used, if required. See 2.1.2.1 Slot number coding for cards in the rear of a VM600 slimline rack.
