Meggitt vibro-meter VM600 User Manual

Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
9-7
Connecting vibration and pressure sensors
CONFIGURATION OF MPC4 / IOC4T CARDS
CAxxx + IPC707
with GSI124
7V
DC
±5 V
AC
8V
DC
±5 V
AC
+24 V
DC
±10%,
55 mA
External supply Figure 9-9
Note: For an IPC707 signal conditioner without diagnostics, the nominal/standing voltage is 7 V
DC
. For an IPC707 with
diagnostics, it is 8 V
DC
(normal operation). Refer to the CAxxx vibration sensors installation manual for further information.
CAxxx + IPCxxx
with GSI124
7V
DC
±5 V
AC
+24 V
DC
±10%,
60 mA
External supply Figure 9-9
CExxx with GSI124
7V
DC
±2 V
AC
+24 V
DC
±10%,
60 mA
External supply Figure 9-9
Displacement probes
TQ4xx + IQS45x
Voltage output:
0to−20V
−20 to −32 V MPC4 / IOC4T Figure 9-4
Current output:
15 to 20 mA
25 mA max. MPC4 / IOC4T Figure 9-5
TQxxx + IQSxxx
with GSI127
Voltage output:
0to−20V
−24 V
DC
±10%,
125 mA
External supply Figure 9-8
TQxxx + IQSxxx
with GSI124
Voltage output:
0to−20V
−24 V
DC
±10%,
85 mA
External supply Figure 9-9
LS12x + ILS73x
Voltage output:
0to10V
18 to 30 V
DC
External supply Figure 9-11
Current output:
4to20mA
170 mA
(600 mA start-up
current)
External supply Figure 9-12
Displacement transducers
AE119
4to12mA for
50 mm.
4to20mA full
scale.
+20to+30V
DC
max. 60 mA
External supply Figure 9-12
Pressure sensors
CP1xx + IPC704 12 mA ±5 mA
+18 V
DC
±10%,
I
max
≤17 mA
External supply Figure 9-5
Table 9-2: Use of an internal (MPC4) or external power supply for various types of sensors (continued)
Transducer or
transducer and
signal conditioner
Output signal
Power supply
rating (required)
Supplied by
Connection
diagram
