Meggitt vibro-meter VM600 User Manual

HARDWARE MANUAL Document reference MAMPS-HW/E
VM600 machinery protection system (MPS) Edition 18 - March 2022
9-52
Assigning alarm signals to relays on the RLC16 card
CONFIGURATION OF MPC4 / IOC4T CARDS
Table 9-7: Jumpers and bus lines associated with relays on the RLC16 card
Line number Jumper settings
Relay
number
(on RLC16)
OC
Bus
Raw
Bus
On IOC4T
(see note 1 and
note 2)
On RLC16 Raw Bus
signal line
used
(see note 2)
To select the
relay
To set the
relay as NE
To set the
relay as NDE
1
0 - - - - - - J1 J82 J81 - - -
- - - 32 J300 J2 J82 J81 0 High
- - - 40 J316 J3 J82 J81 8 High
- - - 48 J332 J4 J82 J81 16 High
- - - 56 J348 J5 J82 J81 24 High
2
1 - - - - - - J6 J102 J101 - - -
- - - 0 J301 J7 J102 J101 0 Low
- - - 8 J317 J8 J102 J101 8 Low
- - - 16 J333 J9 J102 J101 16 Low
- - - 24 J349 J10 J102 J101 24 Low
3
2 - - - - - - J11 J84 J83 - - -
- - - 33 J302 J12 J84 J83 1 High
- - - 41 J318 J13 J84 J83 9 High
- - - 49 J334 J14 J84 J83 17 High
- - - 57 J350 J15 J84 J83 25 High
4
3 - - - - - - J16 J104 J103 - - -
- - - 1 J303 J17 J104 J103 1 Low
- - - 9 J319 J18 J104 J103 9 Low
- - - 17 J335 J19 J104 J103 17 Low
- - - 25 J351 J20 J104 J103 25 Low
5
4 - - - - - - J21 J86 J85 - - -
- - - 34 J304 J22 J86 J85 2 High
- - - 42 J320 J23 J86 J85 10 High
- - - 50 J336 J24 J86 J85 18 High
- - - 58 J352 J25 J86 J85 26 High
6
5 - - - - - - J26 J106 J105 - - -
- - - 2 J305 J27 J106 J105 2 Low
- - - 10 J321 J28 J106 J105 10 Low
- - - 18 J337 J29 J106 J105 18 Low
- - - 26 J353 J30 J106 J105 26 Low
