Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
11 - 3
Definition of screw terminals on the RLC16 card
USING THE RLC16 CARD
Table 11-1: Definition of terminals for J1, J2 and J3 on the RLC16 card
Terminal Name Definition
Connector J1
1 RL1 Relay 1 NC (normally closed) contact
2 RL1 Relay 1 NO (normally open) contact
3 RL1 Relay 1 COM (common) contact
4RL2 Relay2 NC
5RL2 Relay2 NO
6RL2 Relay2 COM
7RL3 Relay3 NC
8RL3 Relay3 NO
9RL3 Relay3 COM
10 RL4 Relay 4 NC
11 RL4 Relay 4 NO
12 RL4 Relay 4 COM
13 RL5 Relay 5 NC
14 RL5 Relay 5 NO
15 RL5 Relay 5 COM
16 RL6 Relay 6 NC
Connector J2
1RL6 Relay6 NO
2RL6 Relay6 COM
3RL7 Relay7 NC
4RL7 Relay7 NO
5RL7 Relay7 COM
6RL8 Relay8 NC
7RL8 Relay8 NO
8RL8 Relay8 COM
9RL9 Relay9 NC
10 RL9 Relay 9 NO
11 RL9 Relay 9 COM
12 RL10 Relay 10 NC
13 RL10 Relay 10 NO
14 RL10 Relay 10 COM
