Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
12 - 3
Definition of the screw terminals on the IRC4 card
USING THE IRC4 CARD
Table 12-1: Definition of connectors on the IRC4 card
Terminal Name Definition
Connector J1
1 RL1 Relay 1 NO (normally open) contact
2 RL1 Relay 1 NC (normally closed) contact
3 RL1 Relay 1 COM contact
4RL2 Relay2 NO
5RL2 Relay2 NC
6RL2 Relay2 COM
7RL3 Relay3 NO
8RL3 Relay3 NC
9RL3 Relay3 COM
10 RL4 Relay 4 NO
11 RL4 Relay 4 NC
12 RL4 Relay 4 COM
13 DB Danger Bypass input (control line)
14 DSI1 Discrete signal interface control input 1 (control line)
15 DSI2 Discrete signal interface control input 2 (control line)
16 GND Chassis ground (return for DB, AR and other DSI inputs)
Connector J2
1RL5 Relay5 NO
2RL5 Relay5 NC
3RL5 Relay5 COM
4RL6 Relay6 NO
5RL6 Relay6 NC
6RL6 Relay6 COM
7RL7 Relay7 NO
8RL7 Relay7 NC
9RL7 Relay7 COM
10 RL8 Relay 8 NO
11 RL8 Relay 8 NC
12 RL8 Relay 8 COM
13 AR Alarm Reset input (control line)
14 DSI3 Discrete signal interface control input 3 (control line)
To Next Page
