HARDWARE MANUAL Document reference MAMPS-HW/E
VM600 machinery protection system (MPS) Edition 18 - March 2022
2-2
Racks
OVERVIEW OF VM600 MPS HARDWARE
Figure 2-1: Views of a typical VM600 rack (ABE040) with several cards installed
(machinery protection cards only)
Front
Side view
Rear view
Front view
(PS2) (PS1)
