Meggitt vibro-meter VM600 - Page 81

Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
2-45
RPS6U rack power supply (ABE04x only)
OVERVIEW OF VM600 MPS HARDWARE
vibro meter
DATA
MATRIX
2D
Figure 2-29: Combined AC-input (120/230 V
AC
) and DC-input panel
with individual inputs
(a) Rear panel
(b) Wiring details
(Rear panel
connections)
(Internal to
VM600 rack)
