Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
2-49
RPS6U rack power supply (ABE04x only)
OVERVIEW OF VM600 MPS HARDWARE
Rated DC supply voltage range:
(Corresponding rack power supply PNR / model)
18-32VDC (200-582-200-xxx / SIM-275D-24)
38.4-57.6VDC (200-582-200-xxx / SIM-275D-48)
57.6-100VDC (200-582-200-xxx / SIM-275D-72)
80-145VDC (200-582-200-xxx / SIM-275D-B0)
Rated AC supply voltage range and its frequency:
(Corresponding rack power supply PNR / model)
115-230VAC 50/60Hz (200-582-500-xxx / SIM-275A)
Maximum active power
Figure 2-32: Example VM600SYS label (earlier versions of VM600 system racks)
