90-830234R3 DECEMBER 1997 FUEL SYSTEM - 3B-13

Carburetor–WME-50/51/52/79/80/81

REF.

TORQUE

REF

NO.

QTY. DESCRIPTION lb. in. lb. ft. N·m

1 CARBURETOR

CARBURETOR 100 - WME-50

1 CARBURETOR

1 CARBURETOR 115 - WME-51

1 CARBURETOR

1 CARBURETOR 125 - WME-52

1 CARBURETOR

1 CARBURETOR 100 - WME-79

1 CARBURETOR

1 CARBURETOR 115 - WME-80

1 CARBURETOR

1 CARBURETOR 125 - WME-81

1 CARBURETOR

2 4 GASKET–fuel bowl

3 4 RETAINING RING

4 4 FUEL BOWL

5 3 THROTTLE SHAFT (WME-1/3/4)

6 1 THROTTLE SHAFT (WME-2)

7 3 THROTTLE LEVER (WME-1/3/4/)

4 THROTTLE VALVE (WME-50/51/52/81)

4 THROTTLE VALVE (WME-79/80)

9 4 FLOAT

10 4 FLOAT SHAFT

11 4 INLET NEEDLE VALVE

12 4 PLUG

13 4 SEAL–drain plug

14 4 GASKET–cover plate

15 4 GASKET–flange
