90-830234R3 DECEMBER 1997 LOWER UNIT - 6A-15
Upper Drive Shaft Bearing
1. Replace upper drive shaft bearing and sleeve if
either are rust stained, or if bearing will not roll
freely. Remove bearing and then sleeve using
Puller Assembly (91-83165M) with suitable jaws.
c
b
a
OR
19177
a - Upper Drive Shaft Bearing
b - Sleeve
c - Puller Assembly (91-83165M)
IMPORTANT: Upper drive shaft bearing/sleeve
must be removed prior to oil sleeve removal. Re-
fer to “Upper Drive Shaft Bearing,” preceding.
Oil Sleeve
1. Remove oil sleeve (if necessary) using Puller As-
sembly (91-83165M) with suitable jaws.
a
b
19222
a - Oil Sleeve
b - Puller Assembly (91-83165M)
IMPORTANT: Upper drive shaft bearing/sleeve
and oil sleeve do not have to be removed for low-
er drive shaft bearing race removal.
