90-830234R3 DECEMBER 1997 POWERHEAD - 4-11
Cylinder Block (3 Cyl.)
(USA-0G127500/BEL-9836633 & UP)
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 CYLINDER BLOCK ASSEMBLY
2 8 SCREW(M10 x 80) 25 33.9
3 1 ADJUSTING SCREW(M6 x 55)
4 1 NUT
5 1 CAP
6 1 CHECK VALVE(PRESS-IN)
7 1 CARRIER ASSEMBLY
8 2 CHECK VALVE
9 3 DOWEL PIN(BEARING RACE)
10 1 DOWEL PIN
11 8 STUD(M10 x 136)
12 8 WASHER
13 8 NUT 45 61
14 1 COVER(BOTTOM)
15 4 SCREW(M8 x 50) 12.5 16.9
16 1 COVER(TOP)
17 1 CARRIER Use where applicable
18 1
GROMMET
19 1 POPPET VALVE
20 1 SPRING
21 1 PLUG KIT
22 12 SCREW(M8 x 35) 18 24.4
23 1 COVER
24 1 GASKET NON OIL INJECTION
25 2 SCREW(M5 x 12) 50 5.6
26 2 WASHER
27 2 STUD
28 2 WASHER
29 2 NUT Drive Tight
To Next Page
