90-830234R3 DECEMBER 1997 MID-SECTION - 5A-9
Swivel Bracket and Steering Arm (80 Jet/100/115/125)
TORQUE
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 SWIVEL BRACKET (BLACK)
1
1 SWIVEL BRACKET (GRAY)
1 SWIVEL BRACKET (TRACKER-GRAPHITE GRAY)
2 1 OIL SEAL (LOWER)
3 2 BUSHING
4 1 O-RING
5 1 SPACER
6 2 GREASE FITTING 40 4.5
7 2 BUSHING
8 2 SCREW 100 11.3
1 SWIVEL PIN/STEERING ARM (BLACK)
9
1 SWIVEL PIN/STEERING ARM (GRAY)
1 SWIVEL PIN/STEERING ARM (TRACKER-GRAPHITE GRAY)
10 1 STEERING LINK ASSEMBLY
11 1 SCREW 20 27.0
12 2 NUT See Exploded View
13 2 WASHER
14 1 BUMPER (X-LONG)
15 1 BUMPER (X-LONG)
1 BOTTOM YOKE (BLACK)
16
1 BOTTOM YOKE (GRAY)
1 BOTTOM YOKE (TRACKER-GRAPHITE GRAY)
17 1 RETAINING RING
18 1 THRUST WASHER
To Next Page
