Mercury 75 Service Manual

90-830234R3 DECEMBER 1997 ATTACHMENTS/CONTROL LINKAGE - 7B-3
Steering Handle Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 STEERING ARM (BLACK)
1
1 STEERING ARM (GRAY )
– 1 GREASE FITTING
2 2 BUSHING
3 1 HOUSING
4 1 PLATE
5 1 GASKET
6 1 SCREW (3/5 IN.) Drive Tight
7 4 SCREW (1/2 IN.) Drive Tight
8 1 CLAMP
9 2 SCREW (M5 x 40) 40 4.5
10 1 NUT Hand Tighten
11 1 THROTTLE HANDLE/STOP SWITCH KIT
12 1 STOP SWITCH
13 1 THROTTLE TUBE
14 1 SCREW (10-16 x 3/8 IN.) Hand Tighten
15 1 GRIP
16 2 CLIP
17 1 NUT 40 54.2
18 1 CONDUIT
19 1 GUIDE TUBE
20 1 BARREL
21 1 SET SCREW 9 1.0
22 1 CABLE
23 1 GUIDE
24 1 ANCHOR
25 2 SET SCREW Drive Tight
26 1 SCREW
27 1 CAP
28 1 WASHER
29 1 WASHER
30 1 SPACER
31 1 WASHER
