Mercury 75 Service Manual

90-830234R3 DECEMBER 1997 ATTACHMENTS/CONTROL LINKAGE - 7B-5
Steering Handle Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 BRACKET ASSEMBLY (BLACK)
1
1 BRACKET ASSEMBLY (GRAY)
2 1 SCREW (3/8-24 x 1-1/4 IN.)
3 1 NUT
4 2 STUD (5/16 x 2-1/2)
5 1 SPACER
6 2 WASHER
7 2 NUT 40 54.2
8 1 GROMMET
9
1 HARNESS ASSEMBLY (22 IN.)
9
1 HARNESS ASSEMBLY (33 IN.)
10 1 PLUG (ELECTRIC)
11 1 KEY SWITCH ( KEYS LISTED UNDER KEY CHART )
12 1 NUT Drive Tight
13 1 COVER
14 6 SCREW (10-16 x 1/2) Drive Tight
15 1 PLUG (NON POWER TRIM)
16 1 STOP SWITCH ASSEMBLY
17 1 LANYARD
18 1 RETAINER
19 1 SCREW (M8 x 1.25 x 50) 110 12.4
20 1 TAB WASHER
21 2 BUSHING
22
1 SHIFT LEVER (BLACK)
22
1 SHIFT LEVER (GRAY)
23 1 WASHER
24 1 STUD (3/8-24 x 1-1/8)
25 1 KNOB
26 1 SHIFT ROD
27 1 ROD END
28 1 BUSHING
29 1 WASHER
30 1 COTTER PIN
31 1 DETENT ASSEMBLY
32 1 TRIM SWITCH POWER TRIM
33 1
NUT Drive Tight
34 1 STOP HARNESS
35 1 CABLE MANUAL
36 1 PLUG
37 1 HORN
38 1 CABLE
39 1 ADAPTOR HARNESS (MANUAL) (Use where Applicable)
40 1 CABLE (RED/YELLOW - 3-1/2 IN. - ELECTRIC)
41 1 BRACKET
42 1 SWITCH ASSEMBLY
43 2 SCREW (M3.5 x 0.6 x 20) Drive Tight
44 1 HARNESS ASSEMBLY (Use where Applicable)
45 1 PLATE
46
1 HARNESS (USA-S/N-0G437999/BEL-9926999 & BELOW)
46
1 HARNESS (USA-S/N-0G4378000/BEL-9927000 & UP)

Mercury 75 Specifications

General

Horsepower	75 hp
Starting	Electric
Cylinders	3
Warranty	3 years
Shaft Length	20 in. or 25 in.
