8. Connect the coolant sensor connector and the fuel pump connector.

a - Coolant sensor connector

b - Fuel pump connector

9. Connect the wires at the starter.

a - Starter connection

b - Starboard exhaust temperature

sensor

10. Connect the starboard and port exhaust temperature sensors.

59364

59363

Engine Wiring Harness
