MERLO PANORAMIC - Nomenclature and Machine Identification

2 - MACHINE TECHNICAL INFORMATION
2 - 2
NOMENCLATURE MACHINE EXTERIOR
Please, pay attention to the identification of the machine sides, because they will be re quoted in the manual.
REF. DESCRIPTION
A
Front side
B
Rear side
C
Left-hand side
D
Right-hand side
P37.12 PLUS - P40.9 PLUS
REF. DESCRIPTION REF. DESCRIPTION
1
Operator cab
9
Fork tilt jack
2
Engine compartment and battery compartment
10
Crossways tilt correction jacks
3
Front axle - brake callipers - wheel reducers
11
First boom
4
Rear axle - brake callipers - parking brake calliper -
wheel reducers
12
Second boom
5
Forks
13
Third boom ((only P37.12 PLUS)
6
Attachment carriage
14
Fuel tank
7
Protection on carriage
15
Hydraulic oil tank
8
Telescopic boom lifting jacks
