LOAD CHART
WARNING! Always observe the load chart.
This paragraph provides instructions to consult the load charts correctly.
To see all attachments, the installation of which in combination with the machine has been approved by Merlo, refer to the file
of diagrams shown at the back of this manual.
DO NOT use any attachment if the corresponding load chart (diagrams file inside the cab and at the back of this
manual) valid for the machine/attachment combination is not present.
The centre of gravity of the load being transported is calculated at 500 mm from the fork heel.
• MACHINE WITHOUT STABILISERS
LIFTING A LOAD
USE CONDITIONS
TRANSPORTING A LOAD
