6 - ORDINARY MAINTENANCE
6 - 24
EVERY 1000 HOURS OR EVERY 12 MONTHS
• ARTICULATED JOINTS
Check the play on the articulated joints of the indicated components. If the play is more than 1 mm, replace the related
bushings.
Lubricate the articulated joints of the indicated components that are equipped with greaser.
A) Wheel reduction hubs - B) Front axle - C) Rear axle - D) Boom - E) Carriage - F) Fork jack
G) Lifting jack - H) Offset jack - L) Stabilisers (if fitted to the machine)
NOTE! A P40.17PLUS has been selected to explain this maintenance operation. The instructions are also valid
for all other machines included in this Operator's Manual.
WARNING!
To use the machine in particularly harsh conditions (dusty, muddy environments, etc) or for continuous and
prolonged daily use, the indicated components must be greased EVERY 50 HOURS or WEEKLY.
