4 - COMMANDS AND INSTRUMENTS
4 - 32
• SELECTING STEERING MODE (29)
The machine relies on a system which allows the operator to choose among 3 steering modes:
A) Four wheel coordinated steering
Use this mode to obtain a narrower steering angle.
B) Front axle steering mode
Use this mode when travelling on public roads.
C) Crab steering
Use this mode to move the machine laterally without losing the longitudinal alignment.
The selection of a different steering mode must be made when the machine is standing still and all wheels are aligned with the
chassis. The correction of a possible misalignment between the front and the rear wheel can be achieved by bringing the
steering wheel to its end stop for a few seconds on one side, then repeat on the other side.
WARNING! Such correction can only be carried out when in "four-wheel" or "crab" mode, even if the
misalignment occurred while using the front axle steering mode.
WINDSCREEN WIPERS AND WINDSCREEN WASHER (34), (7)
FRONT WINDSCREEN WIPER & WASHER SWITCH (34)
Two-positions switch: the first tripping operates the front windscreen wiper, the
second operates the front and the rear windscreen washer.
REAR WINDSCREEN WIPER (7)
Press button (7) to engage the rear windscreen wiper.
