8 - ATTACHMENTS AND OPTIONAL EXTRA
8 - 20
MACHINE
TECHNICALLY PERMISSIBLE MASS (kg)
PERMITTED LOAD ON TYRES PER
AXLE (kg)
TOTAL FRONT REAR FRONT REAR
P37.12 PLUS 8900 5000 5000 5000 5000
P38.12 / PLUS 8900 5000 5000 5000 5000
P38.13 / PLUS / EE 9050 5000 5000 5000 5000
P38.14 / PLUS 9400 5500 5600 5500 5600
P40.9 PLUS 8360 5000 5000 5000 5000
P40.17 / PLUS / EE 10980 5000 6500 5000 6500
P60.10 / EE 10000
7300 7500 7300 7500
P72.10 / EE 10500
• DETERMINATION TABLE OF THE MAXIMUM ALLOWED LIMITS FOR TOWED MASSES
Refer to the following table for information on the maximum allowed limits for towed masses, the determination of the maximum
load on the rear towing hook and the available braking systems for the trailer.
NOTE! The information regarding maximum allowed limits for towed masses are also shown in the type
approval plate in the front part of the cab (see paragraph "IDENTIFICATION AND TYPE APPROVAL PLATES" in
chapter "MACHINE TECHNICAL SPECIFICATIONS").
MACHINE
TOWING CAPACITY (kg)
VERTICAL LOAD ON HOOK (kg)
NO BRAKES
P37.12 PLUS 1500 (on request) 250
P38.12 / PLUS - -
P38.13 / PLUS / EE - -
P38.14 / PLUS - -
P40.9 PLUS - -
P40.17 / PLUS / EE 1250 (on request)
P60.10 / EE
- -
P72.10 / EE
• DETERMINATION TABLE OF THE VIBRATIONS LEVEL (complying with the Directive 78/764/EEC)
The following table contains the vibration values transferred from the driver's seat divided according to the brand and type of
the seat installed on the machine. Check what model is in Your cab and refer to the information shown below.
SEAT MODEL CATEGORY CLASS APPROVAL DRIVER’S MASS
Aws [m/s²] (*)
(Dir.78/764)
KAB Seating 11T6 A I / II / III e11 0997
light 1,13
heavy 1,01
KAB Seating 156, 15T6, 15E1, 15T1 A I / II / III e11 0995
light 1,13
heavy 1,01
SEAT ACTIVIO SERIES – S698 A II / III e13 0021
light 1,64
heavy 0,64
SEAT ACTIVIO SERIES – S55 A II / III e13 0020
light 1,17
heavy 0,98
GRAMMER MSG95 A II / III 100514
light 1,04
heavy 0,64
SEAT FULLY --- --- ---
light 0,68 (**)
heavy 0,55 (**)
(*) Aws = correct value of the rms value of the weighted seat vibration (complying with Directive 78/764/EEC)
(**) according to EN13490:2001
