2 - MACHINE TECHNICAL INFORMATION
2 - 8
REF. DESCRIPTION
1
Telescopic boom control joystick
7
Rear windscreen-wiper switch
12
Pressure gauge for hydraulic system oil or hydrostatic transmission system
13
Spirit level
14
Accelerator pedal
15
Brake pedal
17
Steering wheel trim lock lever
18
Air vent
19
Gear control
20
Drive direction selector
21
Load chart and safety instruction holder
22
Steering wheel
24
Parking lights switch/ low beam lights / Direction indicators / head lights / Horn
26
Lever for the selection of the air suction from inside/outside the cab
27
Driving speed adjustment pedal
28
Small emergency pump for releasing parking brake
29
Steering mode selection lever
34
Front windscreen wiper and screen-washer switch
86
Hand accelerator
135
Stabiliser command switches
(only for models P38.12 PLUS – P38.13 PLUS – P38.14 PLUS – P40.17 PLUS)
C
Instrument panel
D
Attachments dynamic control display
P – P1
Control panels
