Microtest 6632 Series User Manual

84
<Command>
:SWEep:TRACA:PARAmeter
{LS|LP|CS|CP|Q|D|RS|RP|Z|DEG|RAD|R|X|Y|G|B|}
:SWEep:TRACA:PARAmeter?
Function：It sets or queries the PARA of TRACE A
Description：
Set parameterThe first parameter can’t set to OFF. There is no RDC(DC Resistance),
E(Relative Permittivty) and U(Relative permeability) in the sweep mode.
Set syntax
:SWEep:TRACA:PARAmeter Z
Query syntax
:SWEep:TRACA:PARAmeter?
Return data Z (Format is in <disc>)
<Command>
:SWEep:TRACA:YAXis {LOGarithm|LINear}
:SWEep:TRACA:YAXis?
Function：It sets or queries the Y-AXIS of TRACE A.
Description：
Set parameter
LOGarithm | LINear
Set syntax
:SWEep:TRACA:YAXis LOGarithm
Query syntax
:SWEep:TRACA:YAXis?
Return data
LOG | LIN (Format is in <disc>)
<Command>
:SWEep:TRACA:REFerence <value NR3>
:SWEep:TRACA:REFerence?
Function：It sets or queries the REF of TRACE A.
Description：
Set parameterIt can set the value, when Y-AXIS setup is linear mode.
Set syntax
:SWEep:TRACA:REFerence 25k
Query syntax
:SWEep:TRACA:REFerence?
Return data
2.500000E+03 (Format is in <NR3>)
<Command>
:SWEep:TRACA:POSition {-10 ~ 16|MAXimun|MINimum}
:SWEep:TRACA:POSition?
Function：It sets or queries the POS of TRACE A.
Description：
Set parameter
{-10 ~ 16|MAXimun|MINimum}
Set syntax
:SWEep:TRACA:POSition -3
Querysyntax
:SWEep:TRACA:POSition?
Return data
-3 (Format is in <NR1>)
<Command>
:SWEep:TRACA:DIVision <value NR3/disc>
:SWEep:TRACA:DIVision?
Function：It sets or queries the DIV of TRACE A.
Description：
Set parameter The numeric value can only set 1, 2, 5 and 10(when Y-axis setup is linear
mode).
Set syntax
:SWEep:TRACA:DIVision 2k
Query syntax
:SWEep:TRACA:DIVision?
Return data 2.000000E+03 (Format is in <NR3>)
<Command>
:SWEep:TRACA:DECade {1~12}
:SWEep:TRACA:DECade?
Function：It sets or queries the DECADE of TRACE A.
Description：
Set parameter The value of DECADE is {1~12} (when Y-axis setup is LOG mode).
