85
Set syntax
:SWEep:TRACA:DECade 5
Querysyntax
:SWEep:TRACA:DECade?
Return data
5 (Format is in <NR3>).
<Command>
:SWEep:TRACA:MAXimun?
Function： It queries the maximum of TRACE A and corresponding frequency | voltage |
current.
Description：
Query syntax
:SWEep:TRACA:MAXimun?
Return data +2.230924E+06,+3.221517E-03 (Format is in <NR3>).The first data is the
corresponding frequency | voltage | current. The second data is the maximum.
<Command
> :SWEep:TRACA:MINimum?
Function：It queries the minimum of TRACE A and corresponding frequency | voltage | current.
Description：
Query syntax
:SWEep:TRACA:MINimum?
Return data
+2.310130E+06,-3.446227E-03 (Format is in <NR3>).The first data is the
corresponding frequency | voltage | current. The second data is the minimum.
<Command>
:SWEep:TRACA:RESult?
Function：It queries all of the value data of TRACE A.
Description：
Query syntax
:SWEep:TRACA: RESult?
Return data +2.218913E-04,+2.215632E-04,+2.216804E-04…(Format is in <NR3>).
<Command>
:SWEep:TRACB:PARAmeter
{LS|LP|CS|CP|Q|D|RS|RP|Z|DEG|RAD|R|X|Y|G|B|}
:SWEep:TRACA:PARAmeter?
Function：It sets or queries the PARA of TRACE B
Description：
Set parameterThe first parameter can not set to OFF. There is no RDC(DC Resistance),
E(Relative Permittivty) and U(Relative permeability) in the sweep mode.
Set syntax
:SWEep:TRACB:PARAmeter Z
Querysyntax
:SWEep:TRACB:PARAmeter?
Return data
Z (Format is in <disc>)
<Command>
:SWEep:TRACB:YAXis {LOGarithm|LINear}
:SWEep:TRACB:YAXis?
Function：It sets or queries the Y-AXIS of TRACE A.
Description：
Set parameter
LOGarithm | LINear
Set syntax
:SWEep:TRACB:YAXis LOGarithm
Querysyntax
:SWEep:TRACB:YAXis?
Return data
LOG | LIN (Format is in <disc>)
<Command>
:SWEep:TRACB:REFerence <value NR3>
:SWEep:TRACB:REFerence?
Function：It sets or queries the REF of TRACE B.
Description：
Set parameterIt can set the value, when Y-AXIS setup is linear mode.
Set syntax
:SWEep:TRACB:REFerence 25k
Querysyntax
:SWEep:TRACB:REFerence?
Return data
2.500000E+03 (Format is in <NR3>)
