Page #91 background imageLoading...
Page #91 background image
86
<Command>
:SWEep:TRACB:POSition {-10 ~ 16|MAXimun|MINimum}
:SWEep:TRACB:POSition?
FunctionIt sets or queries the POS of TRACE B.
Description
Set parameter
{-10 ~ 16|MAXimun|MINimum}
Set syntax
:SWEep:TRACB:POSition -3
Query syntax
:SWEep:TRACB:POSition?
Return
data -3 (Format is in <NR1>)
<Command>
:SWEep:TRACB:DIVision <value NR3/disc>
:SWEep:TRACB:DIVision?
FunctionIt sets or queries the DIV of TRACE B.
Description
Set parameter The numeric value can only set 1, 2, 5 and 10(when Y-axis setup is linear
mode).
Set syntax
:SWEep:TRACB:DIVision 2k
Query syntax
:SWEep:TRACB:DIVision?
Return
data 2.000000E+03 (Format is in <NR3>)
<Command>
:SWEep:TRACB:DECade {1~12}
:SWEep:TRACB:DECade?
FunctionIt sets or queries the DECADE of TRACE B.
Description
Set parameter The value of DECADE is {1~12} (when Y-axis setup is LOG mode).
Set syntax
:SWEep:TRACB:DECade 5
Query syntax
:SWEep:TRACB:DECade?
Return
data 5 (Format is in <NR3>).
<Command>
:SWEep:TRACB:MAXimun?
Function It queries the maximum of TRACE B and corresponding frequency | voltage |
current.
Description
Querysyntax
:SWEep:TRACB:MAXimun?
Return
data +2.230924E+06,+3.221517E-03 (Format is in <NR3>).The first data is the
corresponding frequency | voltage | current. The second data is the maximum.
<Command>
:SWEep:TRACB:MINimum?
FunctionIt queries the minimum of TRACE B and corresponding frequency | voltage | current.
Description
Query syntax
:SWEep:TRACB:MINimum?
Return data +2.310130E+06,-3.446227E-03 (Format is in <NR3>).The first data is the
corresponding frequency | voltage | current. The second data is the minimum.
<Command>
:SWEep:TRACB:RESult?
FunctionIt queries all of the value data of TRACE B.
Description
Query syntax
:SWEep:TRACB: RESult?
Return
data +2.218913E-04,+2.215632E-04,+2.216804E-04…(Format is in <NR3>).
<Command>
:SWEep:AUToscale
FunctionIt does the AUTO FIT function.
