Touch Pad / Display Panel
Location / Function
During all modes...
When the buttons on the touch pad are depressed, the selection is trans-
formed to the main PC board thru the display panel.
As the main PC board initiates the selected function, informational messages
(time / temp, error codes, etc) appear on the display panel.
Touch Pad
Display Panel
