Technical Information
31
CVA 265x & CVA 266x
4.2 Removing the Coffee Dispensing Nozzle
1. Disconnect the appliance from the power supply.
2. Open the door.
3. Remove the cover (Figure 020-2, Item 3).
4. Remove the two retaining screws (Figure 020-2, Item 2).
5. Press the retainers inward (Figure 020-2, Item 1) and push the coffee
dispensing nozzle towards the front of the appliance to remove.
Figure 020-2: Coffee Dispensing Nozzle Removal
4.3 Display Electronic Cover Removal
1. Disconnect the appliance from the power supply.
2. Open the door.
3. Remove the coffee dispensing nozzle; see Section 020-4.2.
4. Remove the cover retaining screws; see Figure 020-3, Item 1.
5. Remove the cover.
Figure 020-3: Display Electronic Cover Removal (CVA 2650/2660 Shown)
Note:
The display electronic cover on CVA 2652/2662 models has one additional
retaining screw.
1 Retainers
2 Retaining screws
3 Cover
