Miele CVA2650 - Pressure Test; Figure 060-8: Pressure-Measuring Instrument Set; Table 060-14: Brew Unit Position Sensor (B10) Display Codes; Table 060-15: Flow Meter Pulse Rates

Technical Information
90
CVA 265x & CVA 266x
Display Position
Value (Approx.)
Position Explanation
046 Rest
012 Eject
167 Press (with capsule plate only)
150 Service
010 Raised end position
172 Lower end position (with capsule plate only)
Table 060-14: Brew Unit Position Sensor (B10) Display Codes
Number of Pulses Explanation
About 15 Water intake in order (w/o capsule)
<2 (for more than 7 seconds)
Insufficient water intake (F17: Section 060-3.8)
0 (for more than 7 seconds)
No water intake (F10: Section 060-3.7)
Table 060-15: Flow Meter Pulse Rates
4.6 Pressure Test
Required tools:
Figure 060-8: Pressure-Measuring Instrument Set
Note:
A small measuring container will also be required for this test.
1. Let the appliance warm up to normal operating temperature.
2. Remove the capsule magazine from the appliance.
3. Remove the capsule plate (Figure 060-9, Item A).
4. Remove the rubber insert (Figure 060-9, Item B).
1 Connection piece
2 Holding bracket
3 Pressure-measuring instrument
