28
Figure 3-2-2-7
Figure 3-2-2-8
Device Profiles Settings
Item
Description
Default
Name
Enter the name of the device profile.
E.g. Smoker-sensor-app.
Null
Max
TXPower
Enter the maximum transmit power.
The TXPower indicates power levels relative to the Max
EIRP level of the end-device. 0 means using the max EIRP.
EIRP refers to the Equivalent Isotropically Radiated
Power.
0
Join Type
Select from: “OTAA” and “ABP”.
OTAA:Over-the-Air Activation.
For over-the-air activation, end-devices must follow a join
procedure prior to participating in
data exchanges with the network server. An end-device
has to go through a new join
procedure every time as it has lost the session context
information.
ABP: Activation by Personalization.
Under certain circumstances, end-devices can be
activated by personalization. Activation by
OTAA
