Enter the EUI of the device to receive
the payload.
Select the multicast group to send downlinks. Multicast
groups can be added under Multicast Groups tab.
Choose from: “ASCII”, “hex”, “base64”.
Choose the payload type to enter in the payload Input box.
Enter the message to be sent to this device.
Enter the LoRaWAN
®
frame port for packet transmission
between device and Network Server.
After enabled, the end device will receive downlink packet
and should answer “confirmed” to the network server.
Multicast feature does not support confirmed downlink.
Table 3-2-2-12 Send Data to Device Parameters
Show the EUI of the device or multicast group.
Show the used frequency to transmit packets.
Show the used datarate to transmit packets.
Show the signal-noise ratio.
Show the received signal strength indicator.
Show the size of payload.
Show the type of the packet:
JnAcc - Join Accept Packet
JnReq - Join Request Packet
UpUnc - Uplink Unconfirmed Packet
UpCnf - Uplink Confirmed Packet - ACK response from
network requested
DnUnc - Downlink Unconfirmed Packet
DnCnf - Downlink Confirmed Packet- ACK response from
end-device requested
Show the time of packet was sent or received.
Table 3-2-2-13 Packet Parameters
Click to get more details about the packet. As shown:
