Figure 3-3-2-4
IKE Parameter
Item
Description
IKE Version
Select from "IKEv1" and "IKEv2".
Negotiation Mode
Select from "Main" and "Aggressive".
Encryption Algorithm
Select from "DES", "3DES", "AES128", "AES192" and "AES256".
Authentication
Algorithm
Select from "MD5" and " SHA1"
DH Group
Select from "MODP768_1", "MODP1024_2" and "MODP1536_5".
Local Authentication
Select from "PSK" and "CA".
Local Secrets
Enter the preshared key.
XAUTH
Enter XAUTH username and password after XAUTH is enabled.
Lifetime (s)
Set the lifetime in IKE negotiation. Range: 60-86400.
SA Parameter
SA Algorithm
Select from "DES_MD5", "DES_SHA1", "3DES_MD5",
"3DES_SHA1", "AES128_MD5", "AES128_SHA1", "AES192_MD5",
"AES192_SHA1", "AES256_MD5" and "AES256_SHA1".
PFS Group
Select from "NULL", "MODP768_1" , "MODP1024_2" and
"MODP1536_5".
Lifetime (s)
Set the lifetime of IPsec SA. Range: 60-86400.
