Milli-Q Direct 8 User Manual

Milli-Q® Direct 8/16 System 17
Specifications and requirements
Milli-Q

Water
quality
The water delivered from a POD Unit has the following characteristics.
Parameter
Specification
Units
Resistivity
18.2
MΩ.cm @25°C
TOC
≤ 5
ppb
Particulates > 0.22 µm**
< 1
Particulates/mL
Bacteria**
< 0.1
cfu/mL
Pyrogens*
< 0.001
Eu/mL
RNases*
< 0.01
ng/mL
DNases*
< 4
pg/µL
Flow Rate**
0.05 – 1.5
L/min
(*) With BioPak® Final Filter
(**) With Millipak

or BioPak® Final Filter
NOTE:
These specifications are valid if feed water within specification and if correct
maintenance is performed on the system. Some specifications may not be achieved at
start-up.
Weight
The various weights are found in the table below.
System
Operating
Weight (kg)
Dry Weight
(kg)
Shipping
Weight (kg)
Milli-Q® Direct 8
27
20
24
Milli-Q® Direct 16
28
21
25
Electrical
The electrical specifications and data are found in the table below.
Parameter
Value
Voltage
100-230 VAC ±10%
Frequency
50-60 Hz ±10%
Main Fuse
•
3.15 Amp Fast Acting; 5 mm x 20 mm; 250 V safety
voltage.
• The fuse should be serviced by a qualified Millipore
SAS Service Representative.
Power Used
145 VA
Power Cord Length
2.5 metres
Electrical Ground
Earth Grounded
Power Cord use
•
The System is powered on and off by removing the
power cord from the wall outlet.
• The power cord should be plugged into a wall outlet
that is accessible.
Continued on next page

Milli-Q Direct 8 Specifications

General

Resistivity	18.2 MΩ·cm at 25 °C
Total Organic Carbon (TOC)	< 5 ppb
Pyrogens (Endotoxins)	< 0.001 EU/mL
RNases	< 1 pg/mL
DNases	< 5 pg/mL
Display	Touchscreen
Weight	20 kg
Power Supply	100-240 V, 50/60 Hz
Type of Water Produced	Pure and ultrapure water
Flow Rate	Up to 2 L/min
Particulates	<1 particle/mL (>0.2 µm)
Particles > 0.22 μm	< 1 particulate/mL
Particle Size	0.22 µm
Connectivity	USB
Output Water Type	Ultrapure
Dimensions	504 mm x 332 mm x 467 mm (19.8 in x 13.1 in x 18.4 in)
