Milli-Q Direct 8 User Manual

64 Milli-Q® Direct 8/16 System
Dispensing water
Using the
POD Plunger
To dispense water, press down on the POD Unit plunger while in READY Mode.
Position
Water flow
L
Low Flow (push slightly)
M
Medium Flow (push slightly)
H
High Flow (push down and hold, release when done)
H
Continuous high flow (push down and release; push down
again to stop).
Continued on next page
L
M
H

Milli-Q Direct 8 Specifications

General

Resistivity	18.2 MΩ·cm at 25 °C
Total Organic Carbon (TOC)	< 5 ppb
Pyrogens (Endotoxins)	< 0.001 EU/mL
RNases	< 1 pg/mL
DNases	< 5 pg/mL
Display	Touchscreen
Weight	20 kg
Power Supply	100-240 V, 50/60 Hz
Type of Water Produced	Pure and ultrapure water
Flow Rate	Up to 2 L/min
Particulates	<1 particle/mL (>0.2 µm)
Particles > 0.22 μm	< 1 particulate/mL
Particle Size	0.22 µm
Connectivity	USB
Output Water Type	Ultrapure
Dimensions	504 mm x 332 mm x 467 mm (19.8 in x 13.1 in x 18.4 in)
