Milli-Q Direct 8 User Manual

Milli-Q® Direct 8/16 System 65
Dispensing water, Continued
Volumetric
dispensing
Follow the steps below to volumetrically dispense from the POD Unit.
Step
Action
Diagram
1
Make sure the System is in
READY Mode.
2
•
Select Volume.
• Press .
3
•
Adjust the volume of water to
the required value using
and .
• Press .
4
When the volumetric dispensing
is finished, the System
recirculates water for 3 minutes.
5
The System stops recirculating
water.

Milli-Q Direct 8 Specifications

General

Resistivity	18.2 MΩ·cm at 25 °C
Total Organic Carbon (TOC)	< 5 ppb
Pyrogens (Endotoxins)	< 0.001 EU/mL
RNases	< 1 pg/mL
DNases	< 5 pg/mL
Display	Touchscreen
Weight	20 kg
Power Supply	100-240 V, 50/60 Hz
Type of Water Produced	Pure and ultrapure water
Flow Rate	Up to 2 L/min
Particulates	<1 particle/mL (>0.2 µm)
Particles > 0.22 μm	< 1 particulate/mL
Particle Size	0.22 µm
Connectivity	USB
Output Water Type	Ultrapure
Dimensions	504 mm x 332 mm x 467 mm (19.8 in x 13.1 in x 18.4 in)
